UniFi Connect Display Device
Compact, high-performance display controller for UniFi Connect with multi-resolution video output and PoE support for seamless deployment in indoor or outdoor environments.

• Dimensions:

  • Without mount: 123 × 52 × 31 mm (3.5 × 2.1 × 1.2 in)

  • With mount: 125.1 × 56.3 × 40.8 mm (3.6 × 2.1 × 1.4 in)

• Weight: 240 g (5.8 oz) without mount, 260 g (9.2 oz) with mount

• Display Output: HDMI; supports 480p, 720p, 1080p, and 4K video

• Processor & Memory: Octa-core CPU (2 × ARM Cortex®-A78, 6 × ARM Cortex®-A55), Mali-G57 GPU, 8 GB RAM, 32 GB storage

• Connectivity:

  • Wi-Fi 2.4/5 GHz, 802.11 a/b/g/n/ac/ax

  • (1) GbE RJ45 PoE 48 V DC, 0.35 A

  • (1) USB Type-C 5 V DC, 3 A

• Power Method: PoE or USB-C; UL 60950-1 / 62368-1 LPS/PS2 compliant

• Mounting: Pole mount (1–2" / 25–50 mm)

• LEDs: System status LED (white/blue)

• Buttons: Factory reset

• Operating Conditions: 0–40 °C (32–104 °F), 20–90 % RH non-condensing

• Software Integration: Managed via UniFi Connect Web (v3.14.6+) and UniFi Connect Mobile App (iOS/Android v2.18.1+)

• Compliance: NDAA compliant; CE, FCC, IC, Wi-Fi CERTIFIED, UL 62368-1, CSA C22.2 No. 62368-1
