Dimensions
360.9 x 129.6 x 71.4 mm (14.2 x 5.1 x 2.8”)

Weight

• Device: 782 g (1.7 lb)

• With mount: 835 g (1.8 lb)

WiFi Standard
WiFi 5

Spatial Streams
2

Coverage Area
5 km (3.1 mi)

Mounting Locations
Pole

Pole Mount Diameter
0.9—2.4" (24—60 mm)

Weatherproofing
IPX6

Power Method
PoE

Max. Power Consumption
6W

Supported Voltage Range
42.5—57V DC

MIMO
5 GHz: 2 x 2

Max. Data Rate (5 GHz)
400 Mbps (BW40)

Antenna Gain (5 GHz)
17 dBi

Max. TX Power (5 GHz)
25 dBm

Max. Conducted TX Power
25 dBm (Combined)

Antenna Type
Internal

Supported Data Rates

• 802.11ac (WiFi 5): 6.5 Mbps to 400 Mbps (MCS0–MCS9 NSS1/2, VHT 20/40)

• 802.11n: 6.5 Mbps to 300 Mbps (MCS0–MCS15, HT 20/40)

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Channel Bandwidth
20/40 MHz

Wireless Security
WPA2 AES

Networking Interface
(1) GbE RJ45 port

Management
Ethernet, WiFi

Enclosure Material
UV-stabilized polycarbonate

Mount Material
UV-stabilized polycarbonate, stainless steel

Wind Loading
128.2N at 200 km/h

LEDs

• System

• Power

• Ethernet

Button
(1) Factory-reset

Operating Frequency

US/CA:

• U-NII-1: 5150–5250 MHz

• U-NII-2A: 5250–5350 MHz

• U-NII-2C: 5470–5725 MHz

• U-NII-3: 5725–5850 MHz

Worldwide:

• 5150–5875 MHz

Ambient Operating Temperature
-40 to 60° C (-40 to 140° F)

Ambient Operating Humidity
5 to 95% noncondensing

NDAA Compliant
✓

Certifications
CE, FCC, IC
