The UniFi SmartPower Redundant Power System, model USP-RPS, is a proprietary redundant power system designed to protect up to six UniFi SmartPower supported devices from sudden power supply module failure. The USP-RPS continually monitors all attached devices. In the event of an internal AC/DC power supply failure, failover is automatic so your network continues to operate with no interruption in service. With a 950W DC power budget, the USP-RPS can protect a variety of high-power devices, including UniFi PoE switches. An integrated 1.3" color touchscreen LCM displays system information for convenient monitoring.
- General Information
- Manufacturer
- Ubiquiti Inc.
- Manufacturer Website Address
- http://www.ui.com
- Brand Name
- Ubiquiti
- Product Type
- Redundant Power System
- Power Description
- Power Source
- AC/DC
- Physical Characteristics
- Form Factor
- Bracket Mount
- Weight (Approximate)
- 12.13 lb
Dimensions442.4 × 325.6 × 43.7 mm (17.4 × 12.8 × 1.7 in)
Weight
5.5 kg (12.1 lb) without mounting brackets
5.6 kg (12.3 lb) with mounting brackets
Enclosure Material
SGCC steel
Management
Ethernet
Networking Interface
1 × GbE RJ45 port
Power Method
1 × universal AC input, 100–240V AC
Power Supply
54V DC output: AC/DC, internal, 645W
12V DC output: AC/DC, internal, 350W
Supported Voltage Range
100–240V AC
Maximum Power Consumption
995W
Power Output
6 × RPS DC ports
Maximum Power Output
52V DC: 11.54A (600W)
11.5V DC: 30.44A (350W)
Maximum Output Power per RPS Port
52V DC: 11.54A (600W)
11.5V DC: 30.44A (350W)
ESD/EMP Protection
Air: ±16 kV
Contact: ±12 kV
Display
1.3-inch touchscreen
Controls
1 factory reset button
LED Indicators
System, status
USP RPS activity
Environmental
Operating Temperature: -5 to 45°C (23 to 113°F)
Operating Humidity: 10–90% non-condensing
Compliance
NDAA compliant
CE, FCC, IC
