🔧 Technical Specifications

• CPU: Intel® Core™ i9-13900H (14C/20T, up to 5.40GHz, 24MB L3 Cache, 45W TDP)

• Graphics: Intel® Iris® Xe Graphics (up to 1500MHz)

• Memory: 32GB DDR5 5600MHz Dual Channel (16GB × 2)

• Storage: 1TB PCIe 4.0 NVMe M.2 2280 SSD

• Storage Expansion: Triple M.2 2280 PCIe 4.0 ×4 slots (support up to 12TB total)

🌐 Networking & Wireless

• LAN: Realtek RTL8125BG, 2.5Gbps

• Wireless: Wi-Fi 6 (2.4GHz / 5.0GHz), Bluetooth 5.2

🎮 Video & Display

• Quad Display Output

  • 2 × HDMI (4K @ 60Hz)

  • 1 × DisplayPort 1.4 (8K @ 60Hz)

  • 1 × USB-C (USB 3.2 Gen2, Display/Data)

🔌 Interfaces

• 1 × DC Jack Port

• 1 × COM Port

• 1 × Type-C (DP/Data)

• 2 × HDMI

• 1 × DP 1.4

• 4 × USB 3.2 Gen2 (10Gbps)

• 4 × USB 2.0 (480Mbps)

• 1 × RJ45 (2.5Gb LAN)

• 1 × 3.5mm CTIA (Headphone/Microphone)

🖥 Features

• Fan & Power Speed Controls

• Wake on LAN

• Auto Power On

• TDP Power Settings

• Cooling: Large Cooling Fan with Twin Copper Heat Pipes

🔋 Power & Environment

• Power Adapter: 120W DC IN (19V/6.32A), 100–240V AC Input, 50/60Hz

• Operating Environment: –10°C to 45°C, 30%–85% Humidity

• Storage Environment: –20°C to 60°C, 10%–90% Humidity
