Overview
This keyed emergency override provides a manual access solution for UniFi Access Hub deployments, ensuring entry control continuity during power loss or system fault conditions. Designed for professional installations, the device enables authorized mechanical override when electronic authentication is unavailable.
Intelligence
The override integrates with supported UniFi access infrastructure, allowing secure fallback operation while maintaining compatibility with connected locks and strike hardware. Mechanical key operation provides reliable emergency access independent of network or power state.
Features
Engineered for straightforward installation, the override device supports deployment alongside compatible hubs, readers, and locking hardware. Its compact design enables integration into standard access control configurations while enhancing resilience and safety compliance in managed entry environments.
Applications
Emergency access provisions in UniFi-controlled facilities
Commercial or institutional entry points requiring mechanical backup
Industrial deployments requiring failover access capability
Retrofit installations adding manual override functionality
Compatibility
UA-G2-SK-Pro
UA-G3-SK-Pro
UA-G3-SK
UA-G2-SK
UA-Hub-Door
UACC-Lock-Strike-Secure-15mm
UA-Hub-Door-Mini
UACC-Lock-Strike-Safe-15mm
UA-Lock-Magnetic
EAH-8
UA-Hub-Gate
UA-Retrofit-Hub-2
Physical
• Dimensions: Ø60 × 74 mm (Ø2.4 × 2.9")
• Weight: 94 g (3.3 oz)
• Enclosure Material: Polycarbonate
Hardware
• Key Switch: Brass Internal Wave Key; 28 VDC; 4 A
• Terminal Block: COM; NO; NC
• Wire Gauge Support: 18–24 AWG
Environmental
• Operating Temperature: −30°C to +65°C (−22°F to +149°F)
• Storage Temperature: −40°C to +85°C (−40°F to +185°F)
• Operating Humidity: 5%–95% RH (Non-Condensing)
Compliance
• NDAA Compliant: Yes
• Certifications: FCC; IC; CE
