Key Highlights

• Supports 500+ UniFi Devices and 5,000+ simultaneous users

• 12.5 Gbps IDS/IPS throughput for deep security protection

• Up to 5 WAN ports, including 25G SFP28, 10G SFP+, and 2.5G RJ45

• High Availability (VRRP) with hot-swappable dual PSUs

• Rack-mountable (1U) aluminum and SGCC steel chassis

• Unified management through the UniFi Application Suite

Dimensions: 442.4 × 43.7 × 325 mm (17.4 × 1.7 × 12.8”)
Weight: 6.5 kg (14.3 lb)

Performance

• IDS/IPS Throughput: 12.5 Gbps

• Concurrent Sessions: 1,000,000

• SSL/TLS Inspection Sessions: 10,000

• New Sessions per Second: 71,000

The EFG delivers lightning-fast routing, inspection, and traffic handling—perfect for high-density enterprise environments requiring both performance and deep security visibility.

Network & Connectivity

Port Configuration

• 25G SFP28: 2 ports (25G/10G/1G)

• 10G SFP+: 2 ports (10G/1G)

• 2.5G RJ45: 2 ports (2.5G/1G/100M/10M)

WAN Port Options

• Default: (1) 25G SFP28, (1) 2.5G RJ45

• Expandable to 5 total WAN ports

Routing & QoS

• Dynamic Routing: OSPF, BGP

• Advanced QoS, Policy-based Routing, and WAN/VPN traffic management

• IPv6 and IGMP Proxy support

• Integrated RADIUS with RadSec encryption

• Multi-WAN Load Balancing and LTE Failover

Security

Stay protected with a comprehensive, next-gen firewall and threat management suite.

Firewall & Threat Management

• Stateful and Layer 7 Application-Aware Firewall

• SSL Inspection & URL Filtering

• Intrusion Detection and Prevention (IDS/IPS) – 95,000+ threat signatures (CyberSecure Enterprise)

• Deep Packet Inspection (DPI) & Zone-Based Firewall Rules

• VLAN/Subnet-based Segmentation

• Content Filtering & Ad Blocking

VPN & SD-WAN

Empower secure remote access and inter-site connectivity with license-free SD-WAN and multiple VPN options.

Supported VPN Protocols

• WireGuard, OpenVPN, IPsec, L2TP, and Teleport Zero-Configuration VPN

• Identity Endpoint One-Click VPN for simplified secure access

• Site Magic for easy site-to-site VPN deployment

Throughput Performance

• WireGuard / Teleport / Identity VPN: 1.2 Gbps

• IPsec Site-to-Site: 580 Mbps

• OpenVPN: 210 Mbps (Server) / 180 Mbps (Client)

• L2TP: 280 Mbps

Hardware & Reliability

• Processor: 18-core ARM® v8.2 @ 2.0 GHz

• Power Supply: (2) Hot-swappable 150W CRPS modules

• Max Power Consumption: 82W

• Power Input: 100–240V AC, 7A max., 50/60 Hz

• Cooling & Construction: Aluminum CNC + SGCC steel enclosure

• Redundancy: VRRP Gateway Failover + Dual PSU support

User Interface & Protection

• 1.3” Touchscreen Display for quick monitoring

• Bluetooth & Ethernet management

• Factory Reset Button

• ESD/EMP Protection: ±8kV (Air), ±4kV (Contact)

• Operating Temp: 0°–40°C (32°–104°F)

• Humidity: 5–95% non-condensing

Compliance & Certifications

• NDAA Compliant

• Certifications: CE, FCC, IC, Anatel

Software & Management

• Managed via the UniFi Network Application (v5.10.5+)

• Mobile App Compatibility:

  • UniFi iOS™ v10.16.2+

  • UniFi Android™ v10.17.2+

Enjoy centralized visibility, automated configuration, and powerful analytics across all connected UniFi devices.

Why Choose the EFG

• Designed for enterprise-grade throughput and network security

• Integrated SD-WAN and VPN with no licensing fees

• Fully redundant power and failover-ready architecture

• Seamless management through UniFi Network

• Scalable to thousands of devices and users
