Key Specifications

Form Factor & Design

• Dimensions: 203 x 76 x 33 mm (8 x 3 x 1.3")

• Mounting Options: Desktop, wall, or magnetic

• Weight: 320g (device only)

• Enclosure Material: Polycarbonate

• Certifications: CE, FCC, IC, Anatel

• Compliance: NDAA Compliant

• Operating Temperature:

  • PoE++ input: -30 to 60°C (-22 to 140°F)

  • AC adapter: -20 to 45°C (-4 to 113°F)

• Humidity Tolerance: 10%–90% non-condensing

Port Configuration & Power

• Total Ports: 8

  • 7 x PoE+ (802.3at)

  • 1 x PoE++ Input Port

• Supported Data Rates: 10/100/1000 Mbps (1 GbE RJ45)

• Max. PoE Wattage per Port: 30W (PoE+)

• Total PoE Budget:

  • 60W PoE Adapter: 42W

  • 60W AC Adapter: 52W

  • 210W AC Adapter (Optional): 202W

• Max Power Consumption (incl. PoE): 210W

• Power Input Methods:

  • External AC/DC Adapter (Included)

  • PoE++ (DC Input 50–57V)

Switching Performance

• Switching Capacity: 16 Gbps

• Non-blocking Throughput: 8 Gbps

• Forwarding Rate: 12 Mpps

• MAC Address Table Size: 4,000

• VLAN Support: Up to 256 VLANs

Advanced Layer 2 Features

• Spanning Tree Protocol (STP), Rapid STP (RSTP)

• Port Mirroring and Isolation

• Loop Protection

• Jumbo Frame Support

• Storm Control (Multicast/Broadcast Rate Limiting)

• Egress Rate Limiting & Flow Control

Power & Thermal Efficiency

• Heat Dissipation (Non-PoE):

  • 30.7 BTU/hr (PoE input)

  • 27.3 BTU/hr (Adapter input)

Management & Software Compatibility

• Management Interface: UniFi Network Controller

• Minimum Software Version: UniFi Network v8.0.7 or later

• Deployment Requirements: Ethernet uplink required

Ideal Use Cases

• Small office networks requiring multiple PoE devices

• Retail environments with VoIP and security systems

• Satellite branch offices with minimal space

• Layer 2 managed switching with full VLAN and isolation support
