Dimensions

91 x 61 x 32.5 mm
(3.6 x 2.4 x 1.3")

Weight

80 g (2.8 oz)

Enclosure Material

Polycarbonate

Weatherproofing

IPX5

Networking Interface

(2) RJ45 female connectors

Protection & Performance

• ESD/EMP Protection: Absorbs transient current from surge voltages (100V/s to 1kV/µs)

• DC Spark-Over Voltage: 90V @ 100V/s

• Max. Impulse Spark-Over Voltage: 700V @ 1kV/µs

• Discharge Current: 10kA+

• Insulation: Max. Resistance: 1G ohm @ 50V

• Max. Capacitance: 1.0 pF @ 1 MHz

• Data Line Protection: Up to 2.5 Gbps

• PoE Support: ✓

Environmental

• Ambient Operating Temperature: -30 to 65° C (-22 to 149° F)

• Ambient Operating Humidity: 10 to 90% noncondensing

Certifications

• Shock & Vibration: ETSI300-019-1.4 Standard
