This compact Elite Series 1U Network Video Recorder delivers enterprise-grade surveillance performance in a space-efficient form factor designed for professional security deployments. Powered by an industrial-grade embedded processor and a stable Linux operating system, this four-channel NVR supports 4K video processing with advanced H.265 compression to ensure high image quality while maximizing storage efficiency and reducing bandwidth consumption.
Advanced Intelligence Capabilities
Built-in artificial intelligence enhances situational awareness across all four channels. Smart Motion Detection Plus (SMD Plus) classifies detected objects and filters out non-relevant motion events, while Perimeter Protection uses secondary target recognition to eliminate false alarms caused by animals, foliage movement, and lighting changes. Face Detection captures optimized facial snapshots and analyzes six key attributes—gender, age, eyewear, expressions, face masks, and facial hair—enabling more accurate identification and review. Intelligent AI search tools allow rapid investigation by channel, time, event type, face attributes, and human or vehicle classification.
Professional Integration & Connectivity
Designed for flexible deployment as an edge recorder, central NVR, or backup storage device, this system features an open architecture with support for ONVIF Profiles S, T, and G, ensuring seamless integration with third-party IP cameras. Multiple video compression options are supported, including Smart H.265, H.265, Smart H.264, H.264, and MJPEG, providing compatibility across diverse camera ecosystems.
Comprehensive network protocol support—including HTTPS, IPv4/IPv6, SNMP, DDNS, FTP, and P2P—enables secure remote access via iOS and Android mobile devices. Recording modes include manual, alarm-triggered, SMD-based, and intelligent recording, with playback supporting up to four simultaneous channels. Two USB 2.0 ports allow for convenient backup to external storage devices, while RCA audio input and output connections provide full audio integration.
Operating at less than 10 watts of power consumption (excluding HDD), this NVR delivers reliable performance while minimizing operating costs, making it ideal for long-term deployments.
Ideal Applications
This Elite Series NVR is well suited for:
Public safety and municipal monitoring
Educational facility security
Financial and banking surveillance
Transportation and infrastructure monitoring
Water conservancy and utility facilities
City center and urban surveillance networks
System Overview
Processor: Industrial-grade embedded processor
Operating System: Embedded Linux
Operation Interface: Web interface and local GUI
Form Factor: Compact 1U desktop-mounted design
Video & Decoding
Video Channels: 4 IP channels
Resolution Support:
8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 720p, D1
Decoding Capability:
Up to 8 × 1080p @ 30 fps
Multi-Screen Display:
1-view or 4-view layouts
Network & Connectivity
Bandwidth Capacity:
Access: 80 Mbps
Storage: 80 Mbps
Forwarding: 60 Mbps
Network Port:
1 × RJ-45 10/100 Mbps self-adaptive Ethernet
Supported Network Protocols:
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP
SMTP, NTP, DHCP, DNS, IP Filter, DDNS, FTP
Alarm Server, IP Search, P2P, Auto Register
Third-Party Camera Support:
ONVIF, RTSP
Interoperability:
ONVIF Profiles S / T / G, CGI, SDK
Mobile Access:
Android and iOS
Browser Support:
Chrome, IE9 or later, Firefox
Compression
Video Compression:
Smart H.265, H.265, Smart H.264, H.264, MJPEG
Audio Compression:
PCM, G.711A, G.711U, G.726, AAC
Storage & Backup
HDD Interface:
1 × SATA III port
Maximum HDD Capacity:
Up to 10 TB (single drive)
Disk Group Management: Supported
Backup Method: USB storage device
Video & Audio Output
HDMI Output:
1 port (supports up to 4K output resolution)
VGA Output:
1 port
Audio Input:
1 × RCA
Audio Output:
1 × RCA
Recording & Playback
Multi-Channel Playback:
Up to 4 channels simultaneously
Record Modes:
Manual recording
Alarm-triggered recording
SMD recording
Smart recording
Playback Functions:
Play, pause, stop, slow, fast, reverse, frame-by-frame
Full screen, partial zoom, audio on/off
Backup by clip or file
Intelligent Video Analytics
Perimeter Protection:
4 channels
Face Detection:
4 channels
Supports 6 attributes: gender, age, glasses, expression, face mask, beard
SMD Plus:
4 channels with human and vehicle classification
AI Search:
Search by channel, time, and event type
Alarm Functions
General Alarms:
Motion detection, privacy masking, video loss
Scene change detection, PIR alarm, IPC external alarm
Anomaly Alarms:
Camera disconnection, storage error, disk full
IP conflict, MAC conflict, login lockout, cybersecurity events
Intelligent Alarms:
Face detection
Perimeter protection (intrusion and tripwire)
IVS, people counting, heat map, SMD alarms
Alarm Linkage:
Recording, snapshot, audio alert, buzzer
Log entry, preset action, email notification
Power & PoE
Power Supply:
48V / 53V DC, 1.25A / 1.13A
Power Consumption:
< 10W (HDD not included, idle state)
PoE Output:
4 PoE ports
Total PoE budget: 36W
External Interfaces
USB Ports:
2 total (1 × front USB 2.0, 1 × rear USB 2.0)
Environmental Specifications
Operating Temperature:
0°C to +40°C (32°F to 104°F)
Storage Temperature:
0°C to +40°C (32°F to 104°F)
Operating Humidity:
10% to 93%
Storage Humidity:
30% to 85%
Maximum Operating Altitude:
3000 m (9,842 ft)
Physical
Installation: Desktop-mounted
Form Factor: Compact 1U
Certifications
CE:
EN62368-1, EN55032, EN55024, EN55035
EN61000-3-2, EN61000-3-3, EN50130-4
FCC: Part 15 Subpart B
