Video & Audio
Image Sensor
1/2.7" CMOS Sensor
Video Resolution
Default: 2560×1920 (5 megapixels) @20FPS
Lens
f=2.26mm F=2.0, with IR cut
Video Format
H.264
Field of View
• Horizontal: 135°
• Vertical: 100°
• Diagonal: 180°
Pre-Motion Recording
YES
Audio
Two-way audio, noise reduction, echo suppression
Quick Replies
YES
Power
Hardwired
12 24VAC 50/60Hz, DC 24V
Interface
Power
Power port
System
Reset button
Ethernet
One 10M/100Mbps RJ45
Storage
microSD card slot (Max. 256GB), works with Reolink NVR
Audio
Built-in two microphones & one speaker
WiFi
Wireless Standard
IEEE 802.11a/b/g/n
Operating Frequency
2.4GHz/5GHz
Wireless Security
WPA-PSK/WPA2-PSK
Software
Frame Rate
• Mainstream: 2fps - 20fps (default: 20fps)
• Substream: 4fps - 15fps (default: 10fps)
Code Rate
• Mainstream: 1024Kbps - 6144Kbps (default: 4096Kbps)
• Substream: 64Kbps - 512Kbps (default: 256Kbps)
Browsers Supported
Edge, Chrome, Firefox, Safari
OS Supported
PC: Windows, Mac OS; Smartphone: iOS, Android
Smart Alarm
Motion detection/person detection; visitor notification
Recording Modes
Motion recording (default); 24/7 recording; scheduled recording
Protocols & Standards
HTTPS, IPv4, UPNP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Work with
Google Assistant
Rich Notification
YES
Working Environment
Temperature
Operating temperature: -10°C – +50°C (14°F – 122°F)
Humidity
Operating humidity: 10% – 90%
Weatherproof
IP65
Size & Weight
Dimension
133mm (H) ×48mm (W) ×23mm (T)
Weight
96g
Warranty
Limited Warranty
2-year limited warranty. For support, visit https://support.reolink.com/hc/en-us/ .
