AIO Functions    Print, copy, scan (multifunction vers)

Acoustic Power Emissions (active, printing)    5.8 B(A) (operating), <3.4 B(A) (idle)

Acoustic Pressure Emissions    42 dB(A) (operating), <16 dB(A) (idle)

Connectivity, Std    Gigabit Ethernet (1000Base-T), Wi-Fi 802.11b/g/n

Copier Reduce/enlarge    50 to 400%

Dynamic security    Dynamic security enabled printer

Electromagnetic Emission Standard

Compliant with Class B requirements, including USA (FCC rules), Canada (ICES), EU (RED Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI); Korea (KCC)

Energy Star Certified    Yes

Hard Disk    None

Ink Drop Size    6 pl (C, M, Y); 12.6 pl (mK)

Ink Types    Pigment-based (C, M, Y, mK)

Line Accuracy    ±0.1%[2]

Linear Scan Speed (imperial)    Up to 1.5 in/sec (color, 200 dpi), up to 4.5 in/sec (grayscale, 200 dpi)

Manufacturer Warranty    One-year limited hardware warranty. Warranty and support options vary by product, country, and local legal requirements.

Maximum Optical Density (black)    15 L* min/1.7 D

Maximum Scan Length (imperial)    23 ft

Media Handling, Document Finishing    Sheet feed, roll feed, input tray (50 sheet capacity), media bin, automatic horizontal cutter

Media Size Maximum, Imperial (facet)    36

Media Sizes Custom (imperial)    Front-loading input tray: 8.3 x 11 to 12 x 18 in; Manual feed: 8.3 x 11 to 36 x 66 in

Media Sizes Standard (imperial Rolls)    14.5 to 36 in

Media Thickness (imperial)    Up to 0.03 in

Media Types    Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint), technical paper (natural tracing), film (clear, matte), photographic paper (ID satin, ID gloss), self-adhesive (adhesive matte/gloss, adhesive polypropylene gloss), Polypropylene (matte)

Non-Printable Area (imperial cut-sheet)    0.2 x 0.2 x 0.2 x 0.2 in

Non-printable Area Roll Media (imperial)    0.2 x 0.2 x 0.2 x 0.2 in

Operating Humidity Range    20 to 80% RH

Package Dimensions (imperial)    62 x 24.8 x 30.7 in

Post Consumer Recycled Plastic In Hardware by weight of plastic    36%

Power Consumption Description    35 W (printing), <11 W (ready), <3.5 W (sleep), <0.1 W (standby). Auto-scheduled printer on/off usage.

Print Cartridge Volume Delivered (metric)    300 ml, 130 ml

Print Cartridge, Color(s)    Cyan, magenta, yellow, matte black

Print Cartridges, Number    4 (C, M, Y, mK)

Print Head Nozzles    1376 per color; 5504 in total

Print Heads    1 (C, M, Y, mK)

Print Languages, Standard    TIFF, JPEG, URF, PDF, HP-GL/2, HP-RTL, CALS G4

Print Multi-size Files In One Click    Yes

Print Resolution Color (best)    Up to 2400 x 1200 optimized dpi

Print Speed (imperial)    25 sec/page for D size, 90 D size 24" x 36" prints per hour

Print Speed (metric)    25 sec/page on A1, 90 A1 prints per hour

Print Technology    HP Thermal Inkjet

Printer Drivers Included    Raster driver for macOS and Windows, HP-GL/2 driver for Windows

Printing Path    Wi-Fi Direct, remote printing, Apple AirPrint and HP app for Android and iOS devices, Windows and macOS printer drivers, printing support for Chrome OS, print from USB pen drive

Product Dimensions (imperial)    55.4 x 28.3 x 38.1 in

Product Dimensions (metric)    1407 x 720 x 967 mm

Recommended Media    HP Universal Bond Paper (FSC® certified)[6] (recyclable)[7];

HP Coated Paper (FSC® certified)[6] (recyclable)[7];

HP Heavyweight Coated Paper (FSC® certified)[6] (recyclable)[7]

Remote Print Enabled    Yes

Roll External Diameter    100 mm

Roll Maximum Input    1

Roll Maximum Weight    13.6 lb

Safety Approvals and Requirements    USA and Canada (CSA certified);

EU (RED Directive, EN 62368-1 compliant);

Singapore (PSB);

China (CCC);

Mexico (NYCE);

Argentina (IRAM);

India (BIS)

Scan File Format    JPEG, PDF, TIFF

Scan Input Modes    Scan to email, network, and USB;

Scan to cloud, computer, and mobile through HP app

Scan Resolution, Optical    Up to 600 dpi

Scan Size Maximum (flatbed)    36 x 109 in (imperial), 914 mm x 2.77 m (metric)

Scan Size Minimum (flatbed)    5 x 5 in (imperial), 127 x 127 mm (metric)

Scan Type    Sheetfed, CIS (Contact Image Sensor), media jam detection sensor, front feed scanning method

Security Features    HP Secure Boot, whitelisting, Security event logging, Disable network ports and protocols, SNMPv3, 802.1x compatibility, TLS/SSL, Semi-permanent-queue Erase, NTLM v2, HP Web JetAdmin, HP Security Manager, SIEM Integration

Segment (facet)    Business

Software Included    HP Click for Windows and macOS, HP app for Windows, macOS, Android, and iOS

Standard Media Sizes Supported    Input tray: A, B; Manual feed: A, B, C, D, E (imperial), Input tray: A4, A3; Manual feed: A4, A3, A2, A1, A0 (metric)

Standard Memory    2 GB

Storage    2.7 GB reprint queue

Storage Temperature Range    -25 to 55°C (celsius), -13 to 131°F (fahrenheit)

Sub Brand (facet)    DesignJet

Subcategory (facet)    Large format

Supported Applications, Primary    Line drawings; Renderings; Presentations; Maps; Posters

Taxonomy (facet)    Large Format Printers/ Plotters
