Dimensions: 481.4 × 480 × 132 mm (19 × 18.9 × 5.2")
Form Factor: 3U Rack-Mount | Weight: 16.6 kg (36.6 lb) without rails / 19.5 kg (43.0 lb) with rails
Construction: SGCC Steel Enclosure, Aluminum Mount | Supports 482.6 mm (19") Four-Post Racks (650–1,000 mm Depth Range)

Application Suite

• Protect ✓

• Access ✓

• Vantage Point ✓

• Managed Cameras: 210 × HD | 140 × 2K | 70 × 4K

• Managed Access Hubs: 300 Units

• Storage Capacity: 16 × 3.5" Drive Bays with Data Protection ✓

• Door Access Integration: Supported ✓

Networking & Connectivity

• Interfaces:

  • (2) × 10G SFP+ Ports

  • (1) × 10 GbE RJ45 Port

• Redundant Networking & Power Support: ✓

Hardware Specifications

• Drive Support: Up to (16) 2.5"/3.5" HDD or SSD (310W Max Power Budget)

• Power Consumption: 410W Max

• Power Method:

  • Dual Redundant Hot-Swappable AC Inputs (100–240V AC, 7A Max, 50/60Hz)

• Power Supply: (2) × 550W CRPS, Hot-Swappable

• Processor: 8-Core ARM® @ 2.5 GHz

• Memory: 32 GB

• Display: Optional Bezel Display

• Management Interface: Ethernet

• Slide Rails: Included (19" Four-Post Mount)

Environmental & Compliance

• Operating Temperature: –5 to 40°C (23 to 104°F)

• Humidity: 5–95% Non-Condensing

• NDAA Compliant: ✓

• Certifications: CE, FCC, IC
