4K UHD, Sharpen the Details
Coming with 4K 8MP resolution, E1 Outdoor Pro delivers an upgraded visual experience with images and videos that are four times sharper than 1080p. Stay informed with crucial details that are hard to see with the naked eye.
Leap into the New Era of Wi-Fi 6 Technology
Experience seamless, lag-free 4K live streaming powered by the next-gen Wi-Fi 6 technology. With its blazing-fast speed and uninterrupted connection, elevate your home security to a new level without any limits.
Note: *A Wi-Fi 6 router is recommended for optimal performance.
Video & Audio
Image Sensor
1/2.8" CMOS Sensor
Video Resolution
3840X2160 (8.0 Megapixels)@20fps
Lens
f=2.8-8mm Max: F1.6
Video Format
H.265
Field of View
• Horizontal: 94° ~ 50°
• Vertical: 53° ~ 30°
Day & Night
IR-Cut Filter with Auto-Switching
Infrared Night Vision
Up to 12 Meters (40ft); LED: 12pcs/1.6W/850nm
Color Night Vision
4pcs/2.7W/6500K/180Lumens
Audio
Two-Way Audio
Power
DC Power
DC 12.0V⎓1A, <12W
Interface
Power
DC power port
System
Reset Button
Ethernet
One 10M/100Mbps RJ45
Storage
microSD card slot (Max. 256GB)
Audio
Built-in Microphone and Speaker
Pan&Tilt
Pan &Tilt Range
Pan: 355°, Tilt: 0°~50°
Auto Tracking
Support
Wi-Fi
Wireless Standard
IEEE 802.11a/ac/ax/ b/g/n
Operating Frequency
2.4 GHz/5 GHz
Wireless Security
WPA/WPA2/WPA3
Software Features
Frame Rate
• Main Stream: 2fps - 25fps(default: 20fps)
• Sub Stream: 4fps - 15fps(default: 10fps)
Code Rate
• Main Stream: 4096Kbps -8192Kbps(default: 5120Kbps)
• Sub Stream: 64Kbps - 512Kbps(default: 256Kbps)
Browser Supported
Edge, Chrome, Firefox, Safari
OS Supported
PC: Windows, Mac OS; Smartphone: iOS, Android
Smart Alarm
Motion Detection/Person Detection/Vehicle Detection/Pet Detection
Record Mode
Motion Recording (default)/Schedule Recording
Protocols & Standards
HTTPS, SSL, TCP/IP, UDP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
MaximumUser Access
Support up to 12 simultaneous video streams (10 substreams & 2 mainstreams)
20 Users (1 admin account & 19 user accounts);
Smart Home
Google Assistant
Working Environment
Temperature
Operating Temperature: -10°C~+50°C (14°F~122°F)
Humidity
Operating Humidity: 10% ~ 90%
Waterproof
IP64
Size & Weight
Dimension
Φ85x118mm
Weight
415g
Warranty
Limited Warranty
2-year limited warranty with Reolink.
