Compact, multi-WAN independent gateway with full 2.5G support for high-performance networking at small-to-medium sites.
Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server
Up to 2.3 Gbps routing with IDS/IPS
(1) 2.5 GbE WAN port
(4) 2.5 GbE LAN ports, including (1) remappable to WAN
USB-C powered (adapter included)
Managed with UniFi Network 8.1.113 and later
Compact Gateway Router – 2.5G Multi-WAN, NDAA Compliant
Efficient desktop security gateway offering advanced firewall protection, VPN, and SD-WAN functionality. Designed for small offices or edge deployments requiring secure multi-WAN performance in a compact form factor.
Networking Interfaces:
• (1) 2.5 GbE RJ45 WAN
• (4) 2.5 GbE RJ45 LAN (2.5G/1G/100M/10M)WAN Capacity: Up to 4 configurable WAN ports
Performance: 2.3 Gbps IDS/IPS throughput
Security: Stateful & Layer 7 firewall, deep packet inspection, intrusion prevention (IPS/IDS), ad and content filtering, zone-based filtering, 55K+ IDS/IPS signatures (with CyberSecure)
VPN & SD-WAN:
• License-free SD-WAN with load balancing
• VPN protocols: WireGuard, OpenVPN, IPsec, L2TP, Teleport, Site Magic
• Zero-configuration Teleport VPN for remote accessRouting & Network Features:
• OSPF dynamic routing, advanced QoS, NAT (SNAT/DNAT/1:1)
• Integrated RADIUS server and RadSec support
• IPv6, mDNS, and LTE backup failover compatibility
• Internet quality and outage reportingHardware & Power:
• Quad-core ARM Cortex-A53 @ 1.5 GHz, 2 GB system memory
• Power: USB-C 5V DC/3A (adapter included)
• Max power consumption: 9.6W
• Dimensions: 141.8 × 127.6 × 30 mm (5.6 × 5 × 1.2")
• Weight: 520 g (1.1 lb)
• Enclosure: Polycarbonate; compact desktop form factor
• 1 × factory-reset button; LED indicators for Ethernet and system statusEnvironment: Operating temp –10 to 40 °C (14–104 °F); humidity 5–95% non-condensing
Protection: ESD ±8 kV (air), ±4 kV (contact)
Compliance & Certifications: NDAA Compliant; CE, FCC, IC, Anatel (04873-25-08356)
