SCK Elite 128 Channel Network Video Recorder with AI

  • Part: 1002172
$3,569.79

Availability

In Stock

Designed for large-scale commercial and institutional deployments, this Elite Series network video recorder delivers enterprise-grade AI analytics across 128 channels in a robust 2U rack-mount platform. Powered by an industrial-grade processor running embedded Linux, this NVR is purpose-built for expansive surveillance environments such as airports, university campuses, retail chains, and government facilities where high channel density and advanced intelligence are critical.

The system combines recorder-based and camera-based AI processing to deliver comprehensive analytics at scale. Onboard AI supports multi-channel face detection and recognition with massive database capacity, advanced perimeter protection with customizable IVS rules, and SMD Plus intelligent filtering to significantly reduce false alarms. Integrated video metadata analysis enhances situational awareness by classifying human and vehicle attributes for faster investigations.

When paired with AI-enabled cameras, analytics extend across all channels to include facial recognition, ANPR, people counting, crowd distribution, heat mapping, stereo analysis, vehicle density monitoring, and AcuPick smart search for rapid event location.

✓
Enterprise Storage & Resilience: Hot-swappable drive bays with RAID 0/1/5/6/10, iSCSI support, and N+M clustering ensure high availability and zero-downtime maintenance

With advanced cybersecurity compliance, centralized management via web and local GUI, and scalable redundancy built in, this 128-channel Elite Series NVR delivers the performance, intelligence, and reliability demanded by mission-critical surveillance operations.

System Overview

  • Model: NVR-ELHS-128-DH

  • Product Name: Elite 128 Channel Network Video Recorder with AI

  • Channels: 128 IP channels

  • Form Factor: 2U rack-mount, 8 HDD bays

  • Main Processor: Industrial-grade processor

  • Operating System: Embedded Linux

  • Operating Interface: Web UI, Local GUI

  • Security Baseline: 2.3

Video & Audio

  • Supported Resolutions:
    32 MP, 24 MP, 16 MP, 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, 960p, 720p, D1, CIF

  • Compression Formats:
    Smart H.265+, H.265, Smart H.264+, H.264, MJPEG

Decoding Capability

AI Disabled

  • 2 × 32 MP @ 30 fps

  • 2 × 24 MP @ 30 fps

  • 4 × 16 MP @ 30 fps

  • 5 × 12 MP @ 30 fps

  • 8 × 8 MP @ 30 fps

  • 11 × 6 MP @ 30 fps

  • 12 × 5 MP @ 30 fps

  • 16 × 4 MP @ 30 fps

  • 32 × 1080p @ 30 fps

  • 128 × D1 @ 30 fps

AI Enabled

  • 1 × 32 MP @ 30 fps

  • 1 × 24 MP @ 30 fps

  • 2 × 16 MP @ 30 fps

  • 2 × 12 MP @ 30 fps

  • 4 × 8 MP @ 30 fps

  • 5 × 6 MP @ 30 fps

  • 6 × 5 MP @ 30 fps

  • 8 × 4 MP @ 30 fps

  • 16 × 1080p @ 30 fps

  • 80 × D1 @ 30 fps

  • Maximum Decoding: 32 × 1080p @ 30 fps

Network Bandwidth

AI Disabled

  • Incoming: 1280 Mbps

  • Recording: 1280 Mbps

  • Outgoing: 1024 Mbps

AI Enabled

  • Incoming: 640 Mbps

  • Recording: 640 Mbps

  • Outgoing: 512 Mbps

Video Output

  • VGA: 2 ports

    • 1920 × 1080, 1280 × 1024, 1280 × 720

  • HDMI: 4 ports

    • HDMI 1 & 2: Up to 3840 × 2160

    • HDMI 3: Up to 7680 × 4320 (8K output)

AI by Recorder

  • Face Detection:

    • Simultaneous Mode: 8 channels (12 faces/s per channel)

    • Heterogeneous Mode: 5 channels (12 faces/s per channel)

  • Face Recognition:

    • Up to 32-channel FD (by camera) + FR (by recorder)

    • Up to 8-channel FD + FR (video stream mode)

  • Face Database Capacity:

    • 40 databases

    • 300,000 face images

    • 48 GB total capacity

  • Face Attributes:
    Gender, age group, glasses, expressions, face mask, beard

  • Video Metadata:

    • 8 channels (human, motor vehicle, non-motor vehicle)

  • Perimeter Protection:

    • Simultaneous Mode: 32 channels, 10 IVS rules/channel

    • Heterogeneous Mode: 24 channels, 10 IVS rules/channel

  • SMD Plus:

    • 32 channels

    • Human and vehicle filtering to reduce false alarms

AI by Camera

  • Face Detection: 64 channels

  • Face Recognition: 64 channels

  • Perimeter Protection: All channels (64 targets/s)

  • SMD Plus: All channels (128 targets/s)

  • Video Metadata: 64 channels

  • ANPR: All channels (64 targets/s)

  • Supported AI Functions:
    Face detection & recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, people counting, crowd distribution, vehicle density, object monitoring

AcuPick

  • Channels: Up to 64

  • Events: 1 combined event per channel

  • Type: AI by Camera + Recorder

Metadata Attributes

Human

  • Top color, top type, hat, bag, age, gender, umbrella

Motor Vehicle

  • License plate, plate color, vehicle model, vehicle logo, ornaments

Non-Motor Vehicle

  • Vehicle model, vehicle color, number of persons, helmet

License Plate Management

  • Database Capacity: 20,000 plates

  • Lists: Blocklist and allowlist supported

Storage & Redundancy

  • HDD Bays: 8

  • RAID Support: RAID 0 / 1 / 5 / 6 / 10

  • iSCSI: Supported

  • Hot Swap: Yes (drawer-style chassis)

  • Cluster Support: N+M clustering

Additional Features

  • EPTZ: Supported

  • One-Click Arming / Disarming: Supported
