Recorder Specifications

• Video Inputs: 4 analog BNC channels plus support for 4 + 2 IP camera channels

• Camera Compatibility: Supports HDCVI, AHD, TVI, CVBS, and IP cameras up to 6 MP

• Recording Resolution: Up to 5M-N, with support for 4M-N, 1080p, 1080N, 720p, 960H, D1, and CIF

• Compression: AI Coding, H.265+, H.265, H.264+, and H.264 for efficient storage utilization

• Network Bandwidth: Up to 32 Mbps incoming

• Audio: 1 × RCA audio input and 1 × RCA audio output with two-way talk support

• Display Outputs: 1 × HDMI and 1 × VGA output supporting resolutions up to 1920 × 1080

• Maximum Resolution: 5M-N

• Supported Technologies: AHD, Analog, HD-CVI, HD-TVI, and Network IP

Physical Specifications

• Weight: 5 lbs

• Dimensions: 16 × 13 × 6 in
